SYMBOL PARAMETER CONDITIONS VALUE UNIT
BU406D 400
VCBO Collector-base voltage
BU407D
Open emitter
330
V
BU406D 200
VCEO Collector-emitter voltage
BU407D
Open base
150
V
VEBO Emitter-base voltage Open collector 6 V
IC Collector current (DC) 7 A
ICM Collector current-Peak 10 A
IB Base current 4 A
Ptot
Total power dissipation TC=25 60 W
Tj Maximum operating junction temperature 150
Tstg Storage temperature -65
